sciDROP NANO | Scienion

sciDROP NANO

High precision dispensing of nano to microliters.

Electromagnetic Micro Valve

The heart of the new sciDROP NANO technology is an electromagnetic micro valve with an extremely fast response time, creating a jet of controlled dispensed volume and accurate positioning.

sciDROP NANO

Thanks to its versatile dispensing capabilities, sciDROP NANO is geared towards applications:

  • where volumes to be dispensed range between 25nL to 1μL per drop and
  • where lines have to be precisely deposited onto nitrocellulose sheets, lateral flow membranes, dipsticks or other materials.

sciDROP NANO can be implemented in all of our sciFLEXARRAYERs, from R&D to manufacturing environments.

In combination with sciDROP PICO, the total volume range between 10 pL and 100 μL is covered by a single sciFLEXARRAYER instrument.

Versatile Dispensing Capabilities

Thanks to its versatile dispensing capabilities, sciDROP NANO is geared towards applications, where volumes to be dispensed range between 25nL to 1μL per drop, and where lines have to be precisely deposited onto nitrocellulose sheets, lateral flow membranes, dipsticks or other materials.

Compatible with all sciFLEXARRAYERs

sciDROP NANO can be implemented in all of our sciFLEXARRAYERs, from R&D to manufacturing environments.

In combination with sciDROP PICO, the total volume range between 10 pL and 100 μL is covered by a single sciFLEXARRAYER instrument.

Accurate

Accurate dispensing of nano- to microliter volumes for producing arrays and lines.

Stable

Long term dispensing stability.

2 modes

Bulk and aspirate/dispense modes.

Low surface tension

Enables the dispensing of viscous samples (up to 22 mPa/s) and with low surface tension (28 mN/m).

sciFLEXARRAYERs

From R&D to manufacturing environments: all sciFLEXARRAYERs.

Versatile

Versatile dispense channel combinations: from picoliters with sciDROP PICO to microliters with sciDROP NANO.

  • Adapters to enable aspiration from different vials or plates
  • Up to 8 dispensing channels
  • Combined with maximum 4 sciDROP PICO channels
Drop volume 25nL -1μL
Nano Dispensing Capillaries Borosilicate glass
Surface Tension 28 mN/m
Viscosity rate up to 22 mPa.s
Dispense precision <2% CV (with water)
Positioning accuracy +/-100 µm
